Description

PT. Cahaya Kalimas Utama Authorized Distributor of Victaulic

Fitting: (specify choice)
Standard: Ductile iron conforming to ASTM A536, Grade 65-45-12.
Optional: Segmentally welded carbon steel, standard wall, conforming to ASTM A53, Type E or S, Gr. B
Nipples: (specify choice)
3/4 – 6″/DN20 – DN150: Carbon steel, Schedule 40, conforming to ASTM A53, Type E or S, Gr. B
8 – 12″/DN200 – DN300: Carbon steel, standard wall, conforming to ASTM A53, Type E or S, Gr. B
Flanged Adapter Nipples: (specify choice)
Class 125 Flange: Cast iron conforming to ANSI B16.1
Class 150 Flange: Carbon steel conforming to ANSI B16.5, raised or flat face
Class 300 Flange: Carbon steel conforming to ANSI B16.5, raised or flat face
Fitting Coating: (specify choice)
Standard: Orange enamel
Optional: Hot dip galvanized and others. Some fittings supplied electroplated as standard – see product
specifications
Flanged Adapter Nipple Coating: (specify choice)
Standard: None (Unfinished)
Optional: Orange enamel, hot dip galvanized and others
