Body: Bronze
Internals: Bronze and copper alloy, except spring is 316 stainless steel
Valve Bonnet: Bronze
Sight Glasses: Polycarbonate
O-Rings: Nitrile
Gland Nut: Copper alloy
Indicator Pin/Plate: Carbon steel, zinc plated
Handwheel: Malleable iron
Open/Shut Label: Aluminum
Valve Seats: EPDM
Options: TestMaster™II can be specially ordered with the body tapped ¼” NPT for a pressure gauge connection.
Test Port Orifice Sizes:
K5.6/ S.I. 80
K8.0/S.I. 115
Pressure Relief Valve Option:
Relief Valve: ½” Pressure Relief Valve, Watts Regulator Model FP 53L 175 psi
Fittings: Bronze elbows and hose adapters
Drain Hose: Reinforced plastic
Rp11.934.000
PT. Cahaya Kalimas Utama Authorized Distributor of Victaulic
Available Sizes
• 1 – 2″/DN25 – DN50
Maximum Working Pressure
• For grooved ends or threaded ends: 300 psi/2068 kPa/21 bar
• For Series 720 with Pressure Relief Valve or CCCF Version: 175 psi/1206 kPa/12 bar
Function
• Provides a test port and a drain port within the same unit
Test Port
• K5.6/S.I. 80
• Optional: K8.0/S.I. 115
